SAVOX - High Voltage STD Brushless Digital Servo with Soft Start, 0.080sec / 347.2oz @ 7.4V - SAVSB2274SGP
CAD $175.59
Availability:
In stock
Only 4 left
SKU:
23478
Distributor Number
SAVSB2274SGP
Manufacturer Number
SB2274SGP
The Savox SB-2274SGP is a high-performance HV brushless servo engineered for pilots and racers who demand exceptional speed, precision, and reliability. Featuring a powerful brushless motor, hardened steel gears, and support for up to 8.4V operation, it delivers an impressive 30 kg·cm of torque and lightning-fast 0.07 sec/60° response. Ideal for giant-scale aircraft, high-performance RC cars, helicopters, and boats, the SB-2274SGP combines smooth operation, outstanding holding power, and long-term durability in a compact aluminum/composite case.
Key Features
-
High-voltage operation (6.0V–8.4V)
-
Brushless motor for maximum efficiency and longevity
-
Hardened steel gear train for extreme durability
-
Up to 30 kg·cm torque at 8.4V
-
Ultra-fast 0.07 sec/60° transit speed at 8.4V
-
Dual ball bearings for smooth, precise control
-
Water-resistant aluminum/composite case
-
Ideal for giant-scale aircraft, helicopters, boats, and high-performance RC vehicles
-
25T spline compatible with standard Savox/Futaba-style servo arms
-
Soft Start technology for smoother servo movement and reduced gear stress
SPECIFICATIONS
| Operating Temperature | 14° - 122°F (-10° - 50°C) |
| Running Current (No Load) | 180mA @ 6.0V, 220mA @ 7.4V |
| Stall Current (Locked) | 6000mA @ 6.0V, 7400mA @ 7.4V |
| Idle Current | 5mA @ 6.0V, 5mA @ 7.4V |
| Wire Length | 300 +/- 5mm |
| Output Gear Spline | 25 Tooth |
| Bearings | 2BB |
| Operating Travel | 100° (1000 → 2000 µ second) |
| Neutral Position | 1500 µ second |
| Pulse Width Range | 800 → 2200 µ second |
| Maximum Travel | Appx 130° (900 → 2100 µ second) |
| Refresh Rate | 333 Hz |
| Motor Type | Brushless |
More Information
Distributeur numero
SAVSB2274SGP
Numéro Manufacturier
SB2274SGP
Country
Taiwan
Brand
SAVOX
UPC
4710006994536
