DLE Engine - DLE-85cc Gas Engine

This is the DLE-85 Gasoline Engine with Electronic Ignition.

FEATURES: Engine mount specifically designed to dampen vibration
          Exhaust extension on the included muffler aids in installation and
            helps protect the engine and muffler in the event of a hard
            landing
          Ignition module will accept the optional DLE tachometer (DLEG5525)

INCLUDES: DLE-85 Engine with Ignition Module, Spark Plug, Engine Standoffs,
            Engine Mount, Muffler w/Exhaust Extension, Fiber Muffler Gasket
            and Manual

REQUIRES: Unleaded gasoline
          Two-stroke oil
          4.8 - 6V NiMH/NiCd, or 6.6V LiFe or 7.4V LiPo battery for ignition
            (separate receiver style pack can be used) (LiPo & LiFe requires
            voltage regulator)
          Propeller

SPECS:    Displacement:      84.88cc (5.18 cu in)
          Bore:              2.047in (52mm)
          Stroke:            1.574in (40mm)
          Total weight:      5.09lb (2.31kg)
                             Engine:          68oz (1930g)
                             Exhaust:         8.8oz (250g)
                             Ignition module: 4.58oz (130g)
          Output:            8.5hp @ 7500 rpm
          Compression ratio: 9.5:1
          Gasoline/Oil Mix:  30:1
          Suggested props:   25x10, 26x9, 27x8
          Height, Crankshaft Center/top of Cylinder Head: 5.5" (140mm)
          Length, Prop Washer to end of Mount: 7.9" (200mm)
          Center of Vertical Mounting Holes: 2.9" (75mm)
          Center of Horizontal Mounting Holes: 3.9" (100mm)
          Mounting Hole Diameter: 0.20" (5mm)

COMMENTS: The DLE-85 uses the CM6 spark plug (DLEG5626).
          To avoid permanent damage to the electronic ignition system, NEVER
            turn engine over with the system switched on and the plug not
            installed.

          For dimension drawings, see  attache documents
